Aldec Customer Use Cases
The User:
A digital imaging solution provider requiring:
- High speed verification solution
- Big transfers of data required – image processing application. Of most importance was Baud Rate from Hardware to Software and from Software to Hardware.
- AHB-based design
How Aldec Delivered:
- Initially, the user preferred AHB SCE-MI Xtors as their projects used AHB bus. However, after learning of Aldec AXI Xtors, they chose AXI SCE-MI Xtors for their speed
- DVM with SCE-MI setup and runtime interface
- AXI Master and Slave SCE-MI Macro Based Xtors with 1024 data bus to support highest transmission data rate (achieved results higher than user’s requirements)
- HES5XLX660EX board to perform emulation
- The Final Result - The user decided on AXI SCE-MI transactors which use the AHB bus and AHB2AXI bridge to connect with AXI Xtors (for a faster interface). The user is now considering using AXI bus and AXI SCE-MI Transactors in future projects as well. |
